ALUMINUM PROFILE HANDLING & PACKAGING SYSTEM

The Main aluminum packing solution&machinery: Aluminum Wrapping Machine Aluminum bundling system Aluminum profile strapping machine Aluminum profile bundle wrapping machine Accumulation station.

Automatic aluminum profile bagging machine


This is an automatic aluminum profile bag packing machine designed for steel tube feeding & bagging operation. It includes steel tube feeding, bagging, out-feeding and etc. It is a set of efficient, convenient and safe packaging machinery for steel tube bagging.

Basic characters:
a) Automatic PLC program control.
b) Automatic bag sealing.
c) The action time in packing is adjustable for difference packing purpose.
d) Program for precise running.
e) Manual and automatic working mode for easy operation.
f) The inverters for adjusting the speed.
g) Precise temperature control for sealing.
h) Sensor and mechanical limiting stopper for safety.
i) Motor over current protection.
j) The bagging size could be adjusted for different OD of the steel tube.
k) Automatic film feeding system.
l) Automatic entrance conveyor system and outlet conveyor system.
m) Constant temperature heat sealing and cutting system is suitable for film.
n) Smokeless sealing and packing material residual free.
o) Material change easily.
p) The menu of the control screen is in English.
Automatic aluminum profile bagging machine
Technical data:
No. Items Data
1 Packaging material BOPP film/PE
2 Material OD: 100-200mm
ID: 75mm
Thickness: 30-60micron
3 Steel tube length 6000mm
4 Tube size OD:9.5 -50mm
5 Bagging speed App. 10-50 m/min
6 Air supply 5-7 bar
7 Power supply 380v 3p 60Hz
This machine's function is to protect the profiles by heat-sealed nylon material.
An envelope is formed and profile is inside it, the bundles are in-feed continuely but will be cut, separated and conveyed to the discharge system.
