Motion side seal shrinking machine

Description:

MO-600 is widely used in sealing and shrinking packing for mass production packaging. It is full-auto type machine, can acheive auto feeding, auto power conveying, auto bagging then sealing&shrinkage. can be suitable for different heights and width of many different goods.
Side Sealer Shrinking Machine MO-600

Feature：

1.The sealing part of transverse cutter is driven by vertical type, while the longitudinal cutter is sealed by constant temperature side cutter.The sealing line is straight and strong, to achieve the perfect sealing effect.

2.The thermostatic heating sealing and cutting system can be used for sealing and cutting various industrial standard shrink films such as POF. For different packaging specifications,only need hand wheel to adjust, increase reliability, much easier to operate.

3.The longitudinal sealing knife can work sustainably and product length not limited.

4.PLC programmable controller,sealing and cutting system can work continuously and smoothly without replacement, and maintenance operation simple.

5.Feeding length is determined by electric eye detection and timer, which can accurately control the length of the film and make the contraction effect easier to control.

6.Add horizontal and vertical electric eyes. For thin or small packaging, can be easily sealing and packaging.

7.Automatic take-up of scrap,single motor control, will not too loose or too tight and crack, waste easy to remove.

8.According to customer needs, can add automatic blowing function.

9.According to customer needs, can add front feeding power conveyor and out-feeding no power storage stacking.
Side Sealer Shrinking Machine MO-600

Technical Specification: MO-600

Sealing type	side sealing
Power supply	380V/50-60Hz/3phase
Sealing height	≤250 mm
Sealing width	≤600 mm
Product size	width+height≤400 mm
Product length	infinite
Packing capacity	depends on product length
Film type	center-folded polyolefin (POF) film or polyethylene(PE)film
Max film size	860mm(width) x 280mm(outer diameter)
Power consumption	12.5kW
Tunnel oven size	depends on product length
Tunnel conveyor speed	variable
Tunnel conveyor	chains with rotating silicon coated rods
Working height	780-820 mm
Air pressure	≤0.5MPa
Sealing system	Special durable alloyed sealing knife with anti-stick Teflon coats
Operating panel	Siemens colorful touch screen, PLC, Omron temperature controller
Weight	900kg
