Tóm tắt điều hành: This page is for anyone wrapping long cartons and boxes and deciding how to automate the film wrap. It explains what the horizontal stretch wrapping machine shown in the video does, how an overhead wrap head lays film onto a carton as it moves on rollers, and what to verify with a supplier before you commit. The video shows a box being wrapped, and the photos on this page are product-library reference images, not stills from the clip.
Trên trang này: Trang này giúp bạn quyết định điều gì · What the machine shown does · How a carton is wrapped · Những điều cần kiểm tra trước khi mua hàng · Video hiển thị nội dung gì · Danh sách kiểm tra xác minh của người mua · FAQ · Đọc liên quan · Bước tiếp theo
Trang này giúp bạn quyết định điều gì
Long cartons and boxes are awkward to cover by hand, and a machine that runs film over the top as the box moves saves time. This page is based on the video below, which shows a carton wrapping machine at work. It explains how an overhead wrap head applies film to a carton on a roller conveyor, and what to verify with a supplier before you commit.
Note that the machine in the video does not use a closed ring around the product. Film is applied from above by an overhead wrap head while the carton travels on the conveyor. The checklist at the bottom gives you a single request you can send as it stands.
What the machine shown does
The machine shown in the video is a horizontal stretch wrapping machine for long objects. A carton sits on a roller conveyor and moves horizontally through the machine while an overhead wrap head applies transparent stretch film from above. The head moves up and down and works with rollers and an arm to cover the top of the carton as it passes.
In the video the machine has a red painted metal frame with blue support parts, a roller conveyor that runs through the machine, and a yellow clamp that holds the carton while it is wrapped. A fixed red guard is visible at the side.
How a carton is wrapped
The conveyor and the overhead wrap head work together.
- Nuôi. The carton is placed on the roller conveyor at the feed end.
- Giữ. A yellow clamp lowers and holds the carton in place.
- Bọc. Film is drawn from inside the machine, and the overhead wrap head applies it over the top of the carton while the carton moves along the conveyor, building up layers.
- Giải phóng. The clamping head and wrap head lift, and the wrapped carton moves on to the output end.
The machine wraps in a horizontal pass-through way, covering the top and sides of the carton as it travels.
Những điều cần kiểm tra trước khi mua hàng
The video shows the wrapping action, not the specification. Nothing on screen states carton size range, line speed, film data or throughput, so those figures come from the supplier in writing. Start with six facts:
- Bao bì sản phẩm — minimum and maximum carton or box length, width, height and weight.
- Thông lượng — đơn vị mỗi giờ.
- Thiết lập phim — Loại phim, chiều rộng, độ dày và số lớp.
- Mẫu quấn — whether the head covers the full surface or only part.
- Điều khiển — Các chức năng trên bảng điều khiển và nút dừng khẩn cấp.
- Gói an toàn — guards, fencing and certifications.
Mỗi mục đều ảnh hưởng đến quyết định mua hàng. Danh sách kiểm tra bên dưới tóm tắt lại chúng thành một yêu cầu duy nhất mà bạn có thể gửi nguyên trạng.
Video hiển thị nội dung gì
What the video shows is one carton being wrapped by a horizontal stretch wrapper. A long rectangular cardboard carton sits on the roller conveyor and moves through the machine.
A yellow clamp lowers to hold it, and film is drawn from inside the machine. The overhead wrap head applies transparent stretch film over the top as the carton moves, building up multiple layers. When the wrapping is complete, the wrap head and clamp lift, and the wrapped carton continues to the output end.
The machine runs this cycle as the carton moves from left to right. A worker appears near the machine during the run.
What the video does not show is just as important. It does not show carton length, width or weight range, line speed, units per hour, film type, width or layer counts, model, power or voltage. It does not show how the film is cut and sealed. It does not show a closed ring rotating around the product, because the machine in the video applies film from above rather than through a ring.
Direct observation notes from the sampled frames follow one rule: only what is visible is stated, and nothing is guessed from audio, because the clip has background music and no narration. The machine has a red painted metal frame with a glossy surface and blue support parts. A roller conveyor runs through the machine, a yellow clamp holds the carton, and a fixed red guard sits at the side.
A control panel on the machine carries a grey touch screen, black knobs, yellow and red round buttons and a white illuminated button; the text on the screen is not readable in the footage. The product is a long rectangular cardboard carton, brown in color, held horizontally, with film visible over its surface. The photos on this page are product-library reference images from the manufacturer, not stills from the clip.
Danh sách kiểm tra xác minh của người mua
| Hãy hỏi nhà cung cấp về | Vì sao nó quyết định việc mua hàng |
|---|---|
| Min/max carton size and weight | Whether the conveyor holds your cartons |
| Đơn vị mỗi giờ | Liệu nó có theo kịp nhịp độ của bạn hay không |
| Loại phim, chiều rộng, độ dày, số lớp | The film is what protects the carton |
| Kiểu quấn và phạm vi bao phủ | The video shows an overhead wrap head |
| Chức năng bảng điều khiển và nút dừng khẩn cấp | A control panel and buttons appear |
| Safety: guards, fencing, certs | A fixed guard is visible |
Gửi cho nhà cung cấp: Please confirm for the horizontal stretch wrapping machine shown in the demonstration video: (1) the minimum and maximum carton length, width, height and weight; (2) units per hour; (3) film type, width, thickness and number of layers; (4) the wrap pattern and how much of the surface it covers; (5) what the control panel functions are, including the emergency stop; (6) fitted safety devices including guards, fencing and certifications.
FAQ
Does the machine have a ring around the product? No. The video shows film applied from above by an overhead wrap head while the carton moves on the conveyor.
Does the carton rotate? No. The carton moves through the machine on the conveyor and keeps its orientation while the wrap head applies film.
Những vật dụng an toàn nào có thể nhìn thấy được? A fixed guard at the side of the machine and a control panel with buttons. Confirm the full package with the supplier.
Đọc liên quan
- Máy quấn màng co dạng vòng ngang
- Máy quấn màng co ngang và máy quấn màng nằm ngang
- Máy đóng gói ngang tự động và máy đóng gói quỹ đạo
- Gói kéo dài quỹ đạo
- Máy quấn màng co ngang dùng cho các sản phẩm giấy mỏng.
- Automatic Panel Wrapping Machine
Bước tiếp theo
Send the supplier your carton sizes, target output and film requirements, and ask for the six verification figures from the checklist above.
Then confirm the wrap pattern and coverage, since the video shows an overhead wrap head applying film from above rather than a ring.
Then ask about the film cut, the control panel and the safety package, because the video shows the wrap but not the seal or guarding details. Use the trang liên hệ để bắt đầu cuộc trao đổi đó.
