SEMIAUTO PALLET WRAPPER MANUFACTURER

Every month, one container Fhope semiauto pallet stretch wrapper was shipped.Our team provide free consultation for wide selection of leading stretch wrapping machinery.

Pallet Stretch Wrapping Machine-A300

Pallet Stretch Wrapping Machine-A300
Description

Manufactured by Fhope in China, the Fhope series Pallet Wrapper range stands light years ahead of any other and includes an uncompromising grandeur of excellence brought together by the distinction of European engineering and state of the art technology and electronics.The Fhope pre-stretch system is light years ahead all other brands. As a result of its unique development,the film performance far exceeds industry standards with the ability to reduce film usage by over 50%.Fhope are very proud of the revolutionising developments which have resulted in world best recognition,far superior to other supplier.

Controller: PLC system
Tension control: Pre-stretch controller
Operator interface: Separate buttons/Display
Wrap settings: Re-wrap function, overwrap and overlap adjustments
Wrap counters: Independent top, middle and bottom
Cycle counters: Total cycle counter and resettable Counter
Emergency stop: Red mushroom head
Electrical disconnect: Lockable
Electrical enclosure: European approved

Pallet Stretch Wrapping Machine-A300
Pallet Stretch Wrapping Machine-A300

Stretch Film (LLDPE):
Thickness: 0.025mm ,
Width: 500mm
Length : 500m-1500m,
Weight: 15kg/Roll
Film capacity: 500mm width x 76mm dia.
Stretch type: Pre-stretch
Pre-stretch level: 250% (optional 100% to 300%)
Load height sensor: Photocell sensor
Force -control: Variable
Film threading: Fhope design, W film threading pattern.

Bearing type: Ring gear
Start & stop mode: Soft start & stop
Diameter: 1500mm
Maximum turning diameter:  2000mm
Maximum load weight: 1800kg
Turntable elevation: 80mm
Turntable plate thickness: 10mm (Anti-deformation)


Pallet Stretch Wrapping Machine-A300
Pallet Stretch Wrapping Machine-A300Controller: PLC system
Tension control: Pre-stretch controller
Operator interface: Separate buttons/Display
Wrap settings: Re-wrap function, overwrap and overlap adjustments
Wrap counters: Independent top, middle and bottom
Cycle counters: Total cycle counter and resettable Counter
Emergency stop: Red mushroom head
Electrical disconnect: Lockable
Electrical enclosure: European approved


Specification

Item\data A300
Size of the product to be wrapped(adjustable)
MAX load size(L*W*H) 1500mm*1500mm
Min load size(L*W*H) 500 * 500 * 500 mm
Max load height 1800mm
Max weight 2000kg
Machine Specification
Turntable rotation speed 13r/min(adjustable)
Turntable diameter 2000mm
Turntable height 100mm
Carriage Up/down speed

adjustable
Power supply voltage
(adjustable)

Standard 220 Volt 1 Ph-50 Hz
Tower motor power 0.4w
Pre-stretch motor power 0.35w
Turntable motor power 0.75w
Packing efficiency 20-40 loads/hour
Forklifting front & rear
Machine weight 650kg
PLC control
Film sealer
HMI
Pre-stretch
Stretch Film Roll detail
External diameter 150-250mm
Internal diameter 76
Film roll height 500m
Film thickness 0.025mm
Note:
1.“▲”means “Yes”, “ /”means “No”
2. Standard machine configuration listed above. Please contact your sales representative for other available configuration.

Performance Features

More Convenient
  •  Packaging method: Bottom, middle and top wrapping layer can be set from 0-99 winds.
  •  Turntable speed can be adjusted by inverter.
  •  Packing counters: Independent top and bottom.
  •  Film carriage speed can be freely adjusted by inverter.
  •  Wrapping settings: re-wrap function, overwrap and overlap adjustment
  • Portable forklift  from front and rear.
  • Top press, pre-stretch and access ramp for your consideration
  • Customized extended height and turntable size are available

Safer
  • Emergency stop button: Red mushroom head.
  • Turntable plate height: 10mm is much more rigid to anti-deformation when load heavy goods.
  •  Advanced  lock door control on film Loading carriage for guaranteed locking.
  • Film loading Safety Shut-off switch shuts down in automatic condition power when stretch film is loaded

More Effective
  • Up to 40-45 pallets per hour
  • Free from  a large amount of manual operation

More Reliable
  • Reinforced tower and turntable structure
  • Heavy-duty structural steel tubing and frame.
  •  Pre-stretch film  with 250% (100%-300%) pre-stretch ratio.
  • 1 year Warranty & lifelong maintenance and technical support
Semi-automatic stretch wrapping machines are normally used in low volume applications where no more than 30 loads an hour need to be wrapped. These machines require that the load be broughtto the machine either by fork lift (high profile) or by pallet jack (low profile).
