You are here: Home >> Products >>Coil packing machine >> Steel pipe wrapping machine

FHOPE-E Series: Steel pipe wrapping machine

FHOPE-E200





Description:
Fhope-E series is steel pipe wrapping machine mainly used to packaging of steel pipe, rods, copper pipe, profile... which is with highly efficiency and nice packaging for saving labor and material cost.



Features:

1. PLC & HMI for automatic operation with can be connected with production line.

2. Widely packing material applicable.

3. Manual and automatic working mode for easy operation.

4. The converter is adopted to adjust the speed of the ring and rollers

5. Overlap of the packing tape according to requirement.

6. Packaging tension is adjustable by special breaker.

7. Guardrails, soft starts and stop for safety operation.

8.Central positioning for the best packaging

9. Indicator alarms automatically when trouble occurs. Trouble can be shown automatically.

 Note: Can be designed according your specification.



Steel Pipe Wrapping Machine Parameters:

  Fhope-E100 Fhope-E200 Fhope-E300
Voltage (V/Hz) AC 380/50( or your requirement)
Power (KW) 1.5 2.8 6.5
 OD(mm) 50-300 100-600 200-800
Length(mm) 1200-4000 2000-6000 2000-6000
Weight(Kg) 50-300 100-1000 100-4000
Packing material PE/Stretch film/knit belt/VCI paper
Ring speed(r/min) 30-80 30-70 30-60
Wrapping speed 2-12m/min 2-10m/min 2-9m/min
Overlapping rate 20-80%
    steel tube/pipe bundling machine        steel tube bag packing pipe bagging machine
Pipe bundle machine Pipe bag packing machine Pipe bagging machine

Related machines: Horizontal orbital wrapping machine               Horizontal Orbital wrapper

                                       Spiral orbital wrapper                                          Orbital stretch wrapping machine
